25mm C-Mount SWIR Industrial Lens Tamron SMA11F25
€2,398.00 *
Prices plus 19% VAT plus shipping costs
Estimated delivery time 3 - 5 Days
All prices are list prices excl. 19% VAT. In order to see prices for companies or dealers, you need to login or register here.
- Order number: 310061
Tamron SWIR Machine Vision Lens SMA11F25 from the SMA11F series Tamron C-Mount SWIR... more
Product information "25mm C-Mount SWIR Industrial Lens Tamron SMA11F25"
Tamron SWIR Machine Vision Lens SMA11F25
from the SMA11F series
Tamron C-Mount SWIR Machine Vision Lens SMA11F25
The SMA11F25 SWIR industrial lens with 25mm focal length from Tamron's SMA11F series is designed for industrial cameras with 1" sensors (can also be used with 2/3" and 1/2" sensors) and a pixel pitch of 5µm (also for use with Sony's IMX990 / IMX991 sensors). The SWIR Machine Vision lenses already cover a light spectrum from 400nm visible light up to 1,700nm short-wave infrared bandwidth with more than 80% spectrum transmittance. Tamron has successfully reduced the focus shift to a minimum. The SMA11F25 Machine Vision lens is very bright with an aperture of F1.6 and convinces with its short working distance of only 20cm. With only -1.0% the distortion was reduced to a minimum. The lens can be connected to a wide range of machine vision cameras via the C-mount connection. Due to the excellent properties and the broadly displayed light spectrum, the SWIR lens is particularly suitable for food inspection, sorting systems and in the medical field.
Key Features of SMA11F25
- 25mm Focal length
- for Imagers up to 1"
- for Wavelengths from 400nm till 1.700nm
- SWIR lens with minimal focus shift
- 1.3 Megapixel Resolution
- C-Mount connector
- manual Aperture from F1.6 till F22
- ultra low distortion (-1.0%)
Tamron SMA11F25 SWIR technical Specifications
Name
Tamron SMA11F25
Focal length
25mm
Mount
C-Mount
Aperture range
F1.6 - F22
29.1° x 21.9°
20.1° x 15.1°
14.7° x 11.7°
Focus range
0.2m ∼ ∞
Focus control
manual with lock
Iris control
manual with lock
Filter thread
M46 P=0.75
Wave length
400nm ∼ 1.700nm
Wide Band Coating - visible - Short Wave Infrared
Wide Band Coating - visible - Short Wave Infrared
Distortion
-1.0%
Weight
260g
Operating Temperature
-20°C ∼ +60°C
| Lens type: | Fixed Focal Length, SWIR |
| pixel size: | 5 µm |
| Öffnungswinkel (h): | 29,1° |
| M.O.D.: | 0,2 m |
| Sensor: | 1/2 |
| Lens-Mount: | C-Mount |
| Focal length: | 25 mm |
| Resolution: | 1,3 Megapixel |
| Aperture: | F1.6, Manual Aparture |
| F-theta Distortion (-%): | -1.00% |
| Filter Thread: | M46 x 0,75 |
